Mini drum coffee bean roaster
Description:
| Model |
ZF-90 |
| Material |
stainless steel |
| Capacity |
600g |
| Voltage |
110V/220V |
| Power |
14W |
| Gross Weight |
2600g |
| Machine Height |
20cm |
| Machine Length |
38cm |
| Drum Diameter |
14cm |
| Drum Length |
21cm |
| Mesh Aperture |
4.5cm |
1. This machine use electric stove, charcoal, or the old gas stove for heating;
2. Motor speed is 25rpm to ensure the uniformity of baking;
3. Stainless steel drum, mesh distribution, directly observed in assaying the fineness of baked beans;
4. Also be used for peanuts, cashew nuts and chestnuts of making.
Installation Instructions
A. Install motor
1. The bracket screw hole at the bottom of the bolt screw motor, pay attention to the motor shaft center height
consistent with support at the other end of the bearing center.
B. Install drum
1. Drum thick shaft end of motor shaft end insert and tighten the retaining bolt;
2. The roller bearing end into the bearing seat;
3. Overlooking the installation after the completion of the baking machine makes the motor shaft center to the
roller and bearing into a line;
4. Lock the nut of the motor connected to the bracket.
If you want to choice 110V,please leave a message,if not,we will send machine with 220V
